substrate thickness |
Copper foil thickness 0.1mm |
Copper foil thickness 0.2mm |
Copper foil thickness 0.25mm |
Copper foil thickness 0.3mm |
Copper foil thickness 0.4mm |
|
0.25mm |
Al2O3 AlN ZTA |
Al2O3 AlN ZTA |
Al2O3 AlN ZTA |
ZTA
|
/ |
|
0.32mm |
Al2O3 ZTA |
Al2O3 ZTA |
Al2O3 ZTA |
Al2O3 ZTA |
ZTA |
|
0.38mm |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
/ |
|
0.5mm |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
|
0.635mm |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
|
0.76mm |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
|
1.0mm |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
Al2O3 AlN |
|
project |
unit |
Al2O3 |
AlN |
ZTA |
|
Maximum size |
mm |
138*190 |
138*190 |
138*190 |
|
Maximum available size |
mm |
130*180 |
130*180 |
130*80 |
|
Overall dimensional tolerance |
mm |
±0.1 |
±0.1 |
±0.1 |
|
Product thickness tolerance |
/ |
±7% |
±7% |
±7% |
|
line width, line spacing |
mm |
≥0.5 |
≥0.5 |
≥0.5 |
|
warp |
/ |
≤4‰ |
≤4‰ |
≤4‰ |
|
peel strength |
N/mm |
＞5.0 |
＞4.0 |
＞5 |
|
solderability |
/ |
＞95 |
＞95 |
＞95 |
|
thermal cycle count |
(-55℃-150℃) times |
＞45 |
＞35 |
＞110 |
|
Ra of copper surface |
μm |
≤3 |
≤3 |
≤3 |
|
shear strength |
(300μm aluminum wire) gf |
＞1000 |
＞1000 |
＞1000 |
|
Application temperature range |
℃ |
（-55，850） |
（-55，850） |
（-55，850） |
|
hydrogen embrittlement temperature |
℃ |
400 |
400 |
400 |
|
surface treatment |
bare copper Anti-oxidation treatment Thickness of surface nickel plating: 1-7μm Thickness of surface nickel-gold plating: AU 0.075-0.1μm, Ni 1-7μm Surface silver plating thickness: 0.1-0.6μm solder resist ink |
|||
